BGA-60 Belt Guard Aftercooler - Thermal Transfer
No fan motor required via mounting to compressor belt guard. These coolers, built from either round copper tube & fin or bar & plate brazed aluminum construction, allow the use of free airflow from the belt guard on reciprocating compressors. Compact and lightweight, the Belt Guard Series is offered in seven models with capacities from 20-100 SCFM (.57-2.8 KW).
Features
- BRAZED ALUMINUM CONSTRUCTION
- Brazed Bar and Plate Aluminum Core
- Energy Efficient
- High Performance
- High Technology Compact Design
- Rugged Heavy Duty Construction
- Excellent for Heat Recovery
Materials
- Core: Brazed Aluminum Bar & Plate
Rating
- Maximum Operating Pressure 250 PSI (17 BAR)
- Maximum Operating Temperature 350∞F (177∞C)
